MCS350 Thermostat
New international service and mobile app by Tuya Smart Life
Teploluxe Premium – a unique solution that will make your life comfortable and convenient!
It allows you to control the heating system from the touch screen of the device, or using a mobile App. The device maintains a comfortable temperature and provides efficient power consumption.
Teploluxe Premium – a unique solution that will make your life comfortable and convenient!
It allows you to control the heating system from the touch screen of the device, or using a mobile App. The device maintains a comfortable temperature and provides efficient power consumption.
MCS350 Thermostat
New international service and mobile app by Tuya Smart Life
Teploluxe Premium – a unique solution that will make your life comfortable and convenient!
It allows you to control the heating system from the touch screen of the device, or using a mobile App. The device maintains a comfortable temperature and provides efficient power consumption.
Teploluxe Premium – a unique solution that will make your life comfortable and convenient!
It allows you to control the heating system from the touch screen of the device, or using a mobile App. The device maintains a comfortable temperature and provides efficient power consumption.
Detailed user's manual
Detailed user's manual
Possibilities
To control:
Google Assistant
Amazon Alexa
Yandex.Alice
Automatization and scenarios support
- warm water and electric floors
- heating boilers
- radiators and other electric heating devices
- "open window" mode
Google Assistant
Amazon Alexa
Yandex.Alice
Automatization and scenarios support
Features
- Wi-Fi 2.4
- Touch-sensitive control
- 24/7 heating schedule
- Apple Siri voice assistant support
- Power consumption statistics collection
- Temperature charts
- Extended event logs
- Cloud-based timer
- Automatically locked sensor buttons
- Saving settings when the power is OFF for 12 months
Sensors
- 2 temperature sensors: built-in and remote
- Remote floor temperature sensor: NTC 6.8 kOhm
- A possibility to use third parties' remote sensors
- A possibility to correct the air sensor readings by up to ±9 degrees
Parameters
- Power supply: 220 V; 50 Hz, max 16A
- Permissible ambient temperature: from +5 °C to +40 °C
- Dimensions: 9×9×4.1cm
- Protection class: II
- Ingress protection rating: IP21
- Temperature control range: from +5 °C to +45 °C
- Warranty period: 5 years
- Country of manufacture: Russia
Possibilities
To control:
Google Assistant
Amazon Alexa
Yandex.Alice
Automatization and scenarios support
- warm water and electric floors
- heating boilers
- radiators and other electric heating devices
- "open window" mode
Google Assistant
Amazon Alexa
Yandex.Alice
Automatization and scenarios support
Features
- Wi-Fi 2.4
- Touch-sensitive control
- 24/7 heating schedule
- Apple Siri voice assistant support
- Power consumption statistics collection
- Temperature charts
- Extended event logs
- Cloud-based timer
- Automatically locked sensor buttons
- Saving settings when the power is OFF for 12 months
Sensors
- 2 temperature sensors: built-in and remote
- Remote floor temperature sensor: NTC 6.8 kOhm
- A possibility to use third parties' remote sensors
- A possibility to correct the air sensor readings by up to ±9 degrees
Parameters
- Power supply: 220 V; 50 Hz, max 16A
- Permissible ambient temperature: from +5 °C to +40 °C
- Dimensions: 9×9×4.1cm
- Protection class: II
- Ingress protection rating: IP21
- Temperature control range: from +5 °C to +45 °C
- Warranty period: 5 years
- Country of manufacture: Russia
Connection and adjustment
Connection and adjustment
- Click on the + button ("Add Device") in top right corner when you're in the main screen of the selected home-ownership.
- Click on the ▣ button ("Scan") in top right corner when you're in the connection menu and scan this QR-code.
- The app may request to use your smartphone's camera for scanning.
- The Wi-Fi network frequency must be 2.4 GHz, the network name and password must contain only numbers and Latin letters (the maximum length of the network name and password is 32 characters). If there are repeaters, amplifiers or several distributing devices in the room in the signal reception area, it is recommended to make the names of the networks different from each other and connect the device to the nearest access point.
To connect the device, follow the steps below:
1. Run the Tuya/Smart Life App and log in (register if you haven't already).
2. Select or create a house (home-ownership) to which you want to add a new device.
3. Click on the + button ("Add Device") in top right corner when you're in the main screen of the selected home-ownership.
4. Click on the ▣ button ("Scan") in top right corner when you're in the connection menu.
5. Scan the QR-code by your smartphone. You can find QR-code in the instruction for the module (system).
6. Follow instructions on the screen of your smartphone to connect the device.
7. In some cases you can see the popup window with the text "Select the status of the indicator light or hear the beep". If you're trying to connect the device in EZ mode select "Blink Quickly".
You can turn ON the EZ mode by press & hold both "Power" and "+" buttons on the unlocked device.
- After completing the setup, you will be taken to the main screen of the home-ownership, where the device you connected will be added to the home/room, and the connection with the device will be established within a few minutes.
- Sometimes after adding the device, its settings and controls may be unavailable for several minutes. During this time, the firmware is updated, you need to wait for a while.
- For simultaneous control of the device by several users, use the function of inviting the user to the house in the settings.
The Wi-Fi network frequency must be 2.4 GHz, the network name and password must contain only numbers and Latin letters (the maximum length of the network name and password is 32 characters). If there are repeaters, amplifiers or several distributing devices in the room in the signal reception area, it is recommended to make the names of the networks different from each other and connect the device to the nearest access point.
To connect the device, follow the steps below:
1. Run the Tuya/Smart Life App and log in (register if you haven't already).
2. Select or create a house (home-ownership) to which you want to add a new device.
3. Click on the + button ("Add Device") in top right corner when you're in the main screen of the selected home-ownership.
4. Click on the ▣ button ("Scan") in top right corner when you're in the connection menu.
5. Scan the QR-code by your smartphone. You can find QR-code in the instruction for the module (system).
6. Change connection mode from EZ to AP in top right corner when you're in the connection menu.
7. Follow instructions on the screen of your smartphone to connect the device.
8. In some cases you can see the popup window with the text "Select the status of the indicator light or hear the beep". If you're trying to connect the device in AP mode select "Blink Slowly".
You can turn ON the AP mode by press & hold both "Power" and "-" buttons on the unlocked device.
To connect the device, follow the steps below:
1. Run the Tuya/Smart Life App and log in (register if you haven't already).
2. Select or create a house (home-ownership) to which you want to add a new device.
3. Click on the + button ("Add Device") in top right corner when you're in the main screen of the selected home-ownership.
4. Click on the ▣ button ("Scan") in top right corner when you're in the connection menu.
5. Scan the QR-code by your smartphone. You can find QR-code in the instruction for the module (system).
6. Change connection mode from EZ to AP in top right corner when you're in the connection menu.
7. Follow instructions on the screen of your smartphone to connect the device.
8. In some cases you can see the popup window with the text "Select the status of the indicator light or hear the beep". If you're trying to connect the device in AP mode select "Blink Slowly".
You can turn ON the AP mode by press & hold both "Power" and "-" buttons on the unlocked device.
- After completing the setup, you will be taken to the main screen of the home-ownership, where the device you connected will be added to the home/room, and the connection with the device will be established within a few minutes.
- Sometimes after adding the device, its settings and controls may be unavailable for several minutes. During this time, the firmware is updated, you need to wait for a while.
- For simultaneous control of the device by several users, use the function of inviting the user to the house in the settings.
- The Wi-Fi network frequency must be 2.4 GHz, the network name and password must contain only numbers and Latin letters (the maximum length of the network name and password is 32 characters). If there are repeaters, amplifiers or several distributing devices in the room in the signal reception area, it is recommended to make the names of the networks different from each other and connect the device to the nearest access point.
- This method is default for all Tuya/SmartLife Wi-Fi devices. This method may be used only if other methods don't work. It's highly recommended to use QR-code for connecting our devices (see instructions above).
- Don't pay attention to pictures or screen instructions; in this connection mode the app uses common/default sample.
To connect the device, follow the steps below:
1. Run the Tuya/Smart Life App and log in (register if you haven't already).
2. Select or create a house (home-ownership) to which you want to add a new device.
3. Click on the + button ("Add Device") in top right corner when you're in the main screen of the selected home-ownership.
4. Scroll left-side list to the end and choose "Others", after that choose "Others (Wi-Fi)" in the appeared menu.
5. Enter your Wi-Fi name and password and press "Next".
6.1. Turn on the EZ mode by press & hold both "Power" and "+" buttons on the unlocked device.
When the EZ connection mode is turned on, the SC is displaying at the device's screen.
6.2. [Optional] Turn on the AP mode by press & hold both "-" and "Power" buttons on the unlocked device.
When the AP connection mode is turned on, the AP is displaying on the device's screen.
7.1. Press button "Confirm..." or Click on the checkbox in the app (don't pay attention to the title) and press "Next".
7.2. Then you can see the popup window with the text "Select the status of the indicator light or hear the beep". If you're trying to connect the device in EZ mode (default) select "Blink Quickly", if you're trying to connect the device in AP mode select "Blink Slowly".
7.3. [Optional] If you're connecting the device in AP mode, you can see additional instructions, follow them for successful connection.
- After completing the setup, you will be taken to the main screen of the home-ownership, where the device you connected will be added to the home/room, and the connection with the device will be established within a few minutes.
- Sometimes after adding the device, its settings and controls may be unavailable for several minutes. During this time, the firmware is updated, you need to wait for a while.
- For simultaneous control of the device by several users, use the function of inviting the user to the house in the settings.
If you want to use voice assistants like Siri, Google, Alexa or Yandex you need to link your Tuya/SmartLife account to the assistant application. After linking you will have a possibility to add new smart devices. You can find detailed manual in Tuya/SmartLife application (About device > Click logo) and in assistant's app.
Google, Alexa and Yandex have native support for our devices. Some functions may not available due to system or device restrictions.
Siri is partially supported by making commands threw the Tuya/SmartLife app. You must have official Apple Commands application been installed.
Smart Watch functionality depends on availability of Tuya/SmartLife app or Apple Commands for Watch OS.
Google, Alexa and Yandex have native support for our devices. Some functions may not available due to system or device restrictions.
Siri is partially supported by making commands threw the Tuya/SmartLife app. You must have official Apple Commands application been installed.
Smart Watch functionality depends on availability of Tuya/SmartLife app or Apple Commands for Watch OS.
The enabled location feature is only needed to connect devices to the Tuya/SmartLife Cloud Platform. Connecting devices without this permission is not possible or may cause errors due to a number of technical limitations of the smartphone OS.
After connection and initial configuration, the permission to use geolocation can be revoked.
After connection and initial configuration, the permission to use geolocation can be revoked.
